Welded coiled tubing is an essential component in modern oil and gas operations, widely used for well interventions, drilling, and maintenance. Thanks to its continuous length, strength, and adaptability, it has become a go-to solution for many challenging field conditions. But while its applications are well-known, fewer people understand how welded coiled tubing is actually made. This article provides a comprehensive and accessible explanation of the entire manufacturing process, from raw material selection to final quality control, helping you appreciate the precision and technology that goes into every length of tubing.
Before diving into the production process, it’s important to understand what welded coiled tubing is and why it matters. Coiled tubing is essentially a long, continuous pipe wound onto a reel. Unlike traditional drill pipe that must be joined section by section, coiled tubing can be inserted and withdrawn from a well without interrupting operations. This saves time and increases efficiency, especially in live wells.
Welded coiled tubing is produced by taking flat strips of steel or alloy, shaping them into tubes, and joining the edges using welding techniques. It differs from seamless coiled tubing, which is made from a solid billet without any seams. Welded tubing is generally more economical to produce, can be manufactured in longer continuous lengths, and offers a high degree of dimensional flexibility.
The first stage in producing welded coiled tubing is selecting the right raw material. Typically, high-strength, low-alloy steel is used due to its excellent mechanical properties, corrosion resistance, and weldability. In some cases, corrosion-resistant alloys (CRAs) such as stainless steel or nickel-based alloys are chosen for more demanding environments like sour gas or offshore wells.
The metal is usually delivered in coils or flat strips, sometimes referred to as skelp. The quality of this raw material is critical because any imperfections in composition or surface quality can affect the performance and safety of the finished tubing.
Before processing begins, the material is subjected to chemical analysis and mechanical tests to ensure it meets the required standards for strength, toughness, and corrosion resistance.
After raw material inspection, the steel strip undergoes edge preparation. This involves trimming the edges to make sure they are smooth, square, and free of burrs or contamination. Proper edge preparation is vital for producing a strong and uniform weld during the next step.
In many modern facilities, the strip is also cleaned using brushing, solvent baths, or plasma cleaning to remove any oil, dirt, or oxide layers that could interfere with the welding process. Ensuring a clean surface allows for better fusion and minimizes the risk of weld defects.
Once the strip is ready, it enters a forming mill where it is gradually shaped into a round tube. This is done through a series of rollers that gently bend the strip into a circular cross-section. This process needs to be precisely controlled to avoid introducing internal stress or deformities.
At this point, the edges of the strip are brought together but not yet joined. The tube is now essentially a hollow cylinder with a narrow open seam running along its length.
The next step is welding the edges to form a continuous, pressure-tight seam. Most welded coiled tubing is produced using high-frequency electric resistance welding (ERW), where electrical current is applied to the edges, heating them until they reach the proper temperature for fusion. Pressure is then applied to forge the edges together without adding filler material.
Another method sometimes used is laser welding, which offers precision and low heat input, especially in thinner or more exotic materials. Regardless of the method, the goal is a consistent, defect-free weld with mechanical properties equal to or better than the base metal.
After welding, the tube is typically heat-treated—either locally at the weld area or along the entire length—to relieve stresses and restore mechanical properties.
Once welded, the interior and exterior weld beads (the slightly raised seam from the welding process) may be removed using scarfing tools. This ensures a smooth surface and helps prevent flow disruption or erosion in high-velocity fluid applications.
In many cases, the tubing is also polished or pickled to improve surface finish and remove any oxidation that formed during welding. These steps not only improve appearance but also help prevent corrosion during operation.
The newly welded tubing is now subjected to cold working—typically cold drawing or cold rolling—to refine its dimensions, increase strength, and improve surface quality. During this process, the tubing is pulled or rolled through dies to achieve the desired diameter and wall thickness.
Cold working aligns the metal’s grain structure, giving the tubing greater strength and fatigue resistance. It also improves dimensional accuracy, which is essential for ensuring that the tubing performs well under pressure and fits properly in wellbore equipment.
Depending on the grade of steel used and the desired mechanical properties, the tubing may undergo a full-body heat treatment such as normalizing, quenching and tempering, or stress relieving. These treatments restore ductility lost during cold working and ensure consistent mechanical properties throughout the length of the tubing.
Heat treatment is performed in controlled furnaces with strict temperature monitoring to ensure the steel structure develops the required strength and toughness without becoming brittle.
With the tubing now in near-final form, it goes through extensive nondestructive testing to ensure quality and reliability. Common tests include:
Ultrasonic testing: To detect internal flaws or wall thickness inconsistencies.
Eddy current testing: To find surface cracks and welding defects.
Hydrostatic testing: Where the tube is pressurized with water to check for leaks and ensure pressure resistance.
These tests help catch imperfections that could lead to failure in the field. Only tubing that passes all NDT inspections can move forward to final processing.
After quality checks, the tubing is spooled onto large reels. Welded coiled tubing can be produced in continuous lengths exceeding 30,000 feet, which is ideal for long horizontal wells. The tubing is measured, cut, and spooled according to the customer’s specific requirements.
This step also includes labeling and recording batch data, ensuring traceability for every coil produced. Operators can access detailed production records, including the results of inspections and material certifications.
Before leaving the manufacturing facility, the tubing undergoes a final inspection. Workers check for straightness, surface finish, uniform wall thickness, and proper coiling. If the tubing meets all specifications, it is cleaned, capped, and securely packaged for transport.
Proper packaging ensures that the tubing is protected during shipment and ready for immediate deployment once it reaches the job site.
The production of welded coiled tubing is a complex, multi-step process that involves careful material selection, precision welding, cold working, heat treatment, and thorough testing. Each phase must be tightly controlled to produce tubing that meets the high demands of the oil and gas industry.
Modern manufacturing techniques and improved quality control have made welded coiled tubing a reliable and cost-effective choice for many applications. Its flexibility, availability in long lengths, and customizable design make it well-suited for everything from routine well servicing to specialized offshore operations.
As the demand for efficient, high-performance solutions in oilfield operations continues to grow, understanding how welded coiled tubing is made helps operators make better-informed decisions about its use and reliability in the field.
